L type Gear Motor

Dongzhan Drive Industry (Shanghai)Co.,Ltd provides customers with high-quality, reliable, and efficient power, transmission, and control solutions.

Product Specification:


Parameter details

Available Power Range: 15W-400W
Suitable Voltage: 12V/24V/310VDC
Output torque range with gearbox 0.05N.m-100N.m
Motor Speed 2000-4000r/min
Gear ratio range 1:5-1:200
Protection class IP30, IP54, IP65

Product Features

  • 1. Compact size, S1 working duty, low noise, low temperature rising, and long use lifetime.
  • 2. The drive be developed by ourselves and a perfect match with our bldc motor and can fulfill precision control of movement
  • 3. Products can be customized as per CE, UL standards.
  • 4. Warranty is 12 months after delivery, and we also can after-sale service if exceeds.
  • 5. Optional gearbox type: parallel shaft gearbox, right angle gearbox, L type gearbox, planetary gearbox, worm gearbox.
  • 6. Optional accessories: Encoder, Brake, Speed controller, Water-proof connector, Bracket.

Product Application

  • 1. Warehouse Logistics Industry.
  • 2. AGV
  • 3. Automatic Control, Textile Equipment, Converyor System, Packing Machine
  • 4. Motor, Textile, Printing, Food, Metallurgical, Environmental Protection Engineering, Warehouse Logistics Industry.
  • 5. Medical Equipment

L type Gear Motor

Supplier Info

Dongzhan Drive Industry (Shanghai)Co.,Ltd. was established in 2011. From the beginning of its establishment, it has been upholding to provide customers with high-quality, reliable and efficient power, transmission and control solutions.
The company established its own production base in 2014 and currently has more than 80 employees, of whom about 45% are
non-frontline operators. These personnel are active in the R D department, sales service department, incoming inspection production line, process inspection production line, etc. which afford a strong guarantee of reliable quality and continuous improvement.
