Induction AC Gear Motor

Dongzhan Drive Industry (Shanghai)Co.,Ltd provides customers with high-quality, reliable, and efficient power, transmission, and control solutions.

Product Specification:


Parameter details

Available Power Range: 6W-250W
Suitable Voltage: 1-ph 110/220/230VAC,50/60HZ;                3-ph 220/380/415/440VAC, 50/60HZ;
Output torque range with gearbox 0.1N.m-40N.m
Motor Speed 1350rpm under 50hz, 4p; 1650rpm under 60hz, 4p;
Gear ratio range 1:3-1:750
Insulation class B(130°C), EN standards

Product Features

  • 1. Compct size, 4 screwed holes on gearhead, also can be foostand mounted by L type bracket.
  • 2. Gear material is 40Cr., all output shaft is integrated by hot extrusion processing, which can afford stronger impact resistance and strength than spline connection
  • 3. All motors be power up to test withstanding voltage, insulation, noise, temperature rising and appearance.
  • 4. 100% copper wire, cotinuously running is no problem.
  • 5. Special grease be poured into gearhead before delivery, free maintenance.
  • 6. Motor can be customized as per customer’s special requirement.

Product Application

  • 1. Converyor system
  • 2. Pharmaceutical machine
  • 3. Automatic Control, Textile Equipment, Converyor System, Packing Machine
  • 4. Motor, Textile, Printing, Food, Metallurgical,
  • 5. Environmental Protection Engineering, Warehouse Logistics Industry.

Induction AC Gear Motor
