Single Worm Gearbox

Dongzhan Drive Industry (Shanghai)Co.,Ltd provides customers with high-quality, reliable, and efficient power, transmission, and control solutions.

Product Specification:

Description

Parameter details

Output Flange size: 65mm,75mm,90mm,110mm,  140mm,170mm, 210mm round.
Output Torque Range: Rated 25N.m-1020N.m                                  Max output: 1.5 times than Rated
Available Gear Ratio 1:1, 1:1.5, 1:2, 1:3
Backlash P2≤6arcmin

Product Features

  • 1. The gear material is high-quality alloy steel with carbonitriding heat treatment to obtain the best wear resistance and impact toughness.
  • 2. Using ANSYS technology to carry out finite element analysis on the gear strength, and at the same time to modify the tooth profile and lead to reduce the impact and noise of gear meshing and increase the service life of the gear system.
  • 3. The output planet carrier adopts an integrated (double-supported) structure design, and the front and rear bearings are distributed in the box with a large span to form a stable integrated structure to ensure high torsional rigidity and accuracy.
  • 4. The gear ring and the output housing adopt an integrated design, using high-quality steel and hot-forged to obtain a higher material density. The integrated design can ensure that all geometric dimensions are processed simultaneously. Compared with other embedded and clamped structures, it has higher precision and strength.
  • 5. The input shaft and the locking device adopt an integrated design, and the double bolts are symmetrically distributed to achieve dynamic balance. At the same time, the strong locking of the double bolts effectively prevents the motor shaft from slipping and realizes high-precision and zero-backlash power transmission.

Product Application

  • 1. Aerospace, Military Industry.
  • 2. Medical health, Electronic Information Industry.
  • 3. Industrial robots, Production Automation, CNC machine tool manufacturing Industry.
  • 4. Motor, Textile, Printing, Food, Metallurgical, Environmental Protection Engineering, Warehouse Logistics Industry.

Single Worm Gearbox
