Description
Parameter details
| Available Power Range: | ≤150W/12VDC;                             ≤300W/24VDC;                   ≤400W/48VDC;                  ≤500W/60VDC; | |
| Input voltage: | 12V-80VDC | |
| Max Current | 30A | |
| Adjustable Range | 0%-100% | |
| Net Weight | 200g | |
| Measurement | 110*77*35mm（controller）92*69*13mm（Panel） | |
Product Features
- 1. Over-current protection, when reaches 20A, the controller stops working until restarting then work
- 2. Low starting and low stop times can be set
- 3. Smallest and max speeds can be set
- 4. Speed adjustment interval value can be set
- 5. Speed regulation by controlling the output voltage
- 6. Support external potentiometer controls and button controls
Product Application
- 1. Industrial electrical control cabinet
- 2. Toy
- 3. Agriculture machinery
- 4. Other place with max current no more than 30A
