SK Built-in Speed Controller

Dongzhan Drive Industry (Shanghai)Co.,Ltd provides customers with high-quality, reliable, and efficient power, transmission, and control solutions.

Product Specification:


Parameter details

Available Power Range: 6W-250W
Input voltage: 1-ph 110/220/230VAC,50/60HZ
Output speed range 50hz,4p: 90-1350rpm;                   60hz,4p:90-1680rpm;
Net Weight 400g
Measurement 68*60*96mm(controller)

Product Features

  • 1. Uising MCU digital control technology,motor output speed is stable, no vibration
  • 2. Motor speed can be display on panel
  • 3. Controller can be mounted into electrical control cabinet and connect with PLC
  • 4. Low starting and low stop time can be set
  • 5. With stall protection function 6. Support Panel control, knob control and 0-10v analog control

Product Application

  • 1. Converyor system
  • 2. Pharmaceutical machine
  • 3. Automatic Control, Textile Equipment, Converyor System, Packing Machine
  • 4. Motor, Textile, Printing, Food, Metallurgical,
  • 5. Environmental Protection Engineering, Warehouse Logistics Industry.
